Technical specifications
Power supply:115/230 V AC, 50/60 Hz
Power consumption:3500.00 W
Output power:625 W RMS (8 ohms)
Dimensions:Width: 48.3 cm
Depth: 49 cm
Height: 8.9 cm
Weight:17.20 kg
Power range:230 V ±10 % (207-253 V)
Power output sine:
Stereo 4 ohms2 x 1000 W
Stereo 8 ohms2 x 625 W
8 ohms bridged1 x 1875 W
Frequency range:40-40000 Hz, ±3 dB
Damping factor:>400
Distortion factor:0.01 %
Signal-to-noise ratio:90 dB
Channel seperation (at 1 kHz):70 dB
Min. input sensitivity:0.77 V/26 dB/1.4 V
Input impedance:20 kohms (balanced)
Slew rate:60 V/µsec
Input connectors:2 x XLR female plug, 2 x 6.3 mm jack plug
Output connectors:2 x Speaker (stereo), 1 x Speaker (bridge), 2 x Banana/screw combination
Control elements:Power switch, input attenuators (one per channel), Mode switch - Stereo/Parallel/Bridged, Ground Lift, Input-Level-Select (0.77 V/26 dB/1.44 V), limiter
LED indicators (per channel):Power, Protect, Signal, Mode
Protection circuits:Short-circuit, DCt, thermal, softstart
Construction:Steel chassis, aluminum front panel
Minimum mounting depth:510 mm
Packaging units
PUEANWeightDimensions
1402639714586118,50 kg51cm x 49cm x 15cm
Spare parts
Diode 1N 4148 100V 200mA 4ns
Transistor A 1837
Transistor C 4793
Transistor D 667A
Transistor B 647
Transistor 2SD 667
E4000148
Resistor 0,47 Ohm 5W Radial Leaded metal layer
Downloads
Spezifications
NameVersionLanguage
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral
Illustration
NameVersionLanguage
10451180-Illustration-8030-en.pdf (4 MB)0.0000en
Press report
NameVersionLanguage
Service document
NameVersionLanguage
10451180-Service-5786-2.0000-de.pdf (169 KB)2.0000de
All images
NameVersionLanguage
10451180-Images-.zip
...
Audio
 / Amplifier
 / Amplifiers

OMNITRONIC P-2000 Amplifier, 2x1000W/4ohm

Powerful PA amplifier for large stages-MainBild
Double tap or pinch to zoomHover to zoom
Bildergalerie öffnen
Detail images (2 overall)
Powerful PA amplifier for large stages-Bild-1
Powerful PA amplifier for large stages-Bild-2
OMNITRONIC

OMNITRONIC P-2000 Amplifier, 2x1000W/4ohm

The article is no longer in our assortment.
No. 10451180

Powerful PA amplifier for large stages

  • 2 x 1000 W/4 ohm
  • Enormous power with highest brilliance
  • 2 gain controls on the front panel
  • All operation modes controllable via LEDs
  • LED intensity adjustable via brightness control on the rear panel
  • Signal inputs via XLR female or 6.3 mm jack socket
  • Input sensitivity adjustable via selector on the rear panel
  • Speaker connection via lockable Speaker plugs or Banana/screw combination
  • With limiter
  • Ground Lift switch against humming
  • Bridged switch for bridging
  • Many protection circuits for optimized equipment protection
  • Very rugged housing
  • Rack installation
  • High power/weight-relation
