Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Fuse:
5 x 20 mm, T 8 A fuse replaceable
Frequency range:
20 - 20000 Hz
S/N ratio:
>100 dB
THD:
<0.05 % at 1 kHz
Impedance:
Input: 20 kOhm , bal. Input: 10 kOhm , unbal.
Gain:
29 dB/ 0.775 V
Housing color:
Black matte
Circuitry:
Class D
Slew rate:
>20 V/µs
Damping factor:
>300
Control elements:
Power switch, level control per channel
Controls:
Softstart; overheat; overload; short-circuit; DC voltage
Status LED:
Power, signal, clip
Connections:
Input: line via 6 x 3-pin XLR Input: 6 x screw plug-in terminal Link: line via 6 x screw plug-in terminal Output: speaker via 6 x screw plug-in terminal
List price excl. 19% VAT Prices in retail stores may vary.
No. 10451638
1 U
Class D multi-channel PA amplifier with SMPS, 6 x 200 W RMS (4 ohms), 6 x 150 W RMS (8 ohms)
Extremely low weight and height due to integrated switch mode power supply
Level control per channel
(19") 48.3 cm rack installation 1 U
For application areas such as: Clubs/dancing school; installation; mobile use; mobile djs / entertainer; restaurants, bars and hotels; rental; sports centres/gyms
