Technical specifications

Power supply:	115/230 V AC, 50/60 Hz
Power consumption:	8.00 W
Protection class:	Protection class II
Power connection:	Fixed power supply cord with Euro plug
Frequency range:	20 - 20000 Hz
Drive type:	Belt drive Brushless DC motor
Drive:	Start time: 1 sec. Stop time: 1 sec. Speed change time: <1s 1kHz 5cm/sec
Wow and flutter:	<0.25 % WRMS
Rumble:	50 dB DIN B
Speed:	33 RPM; 45 RPM
Tone arm:	S-shape with Cardan''s suspension Length: 220 Overhang: 10 mm Stylus pressure: 3-4 g
Output level:	Phono 1.5-3.6 mV/ 1 kHz 5 cm/sec Line 90-216 mV/ 1 kHz 5 cm/sec
Connections:	Output: line/phono via stereo RCA Output: USB B (F) mounting version
Pitch range:	±10%
USB port:	1 x USB 1.1, type B
Material:	Plastic
Color:	Silver
PC connect:	Via USB
Dimensions:	Width: 45 cm Depth: 36 cm Height: 14.5 cm
Weight:	3.90 kg
Operating system:	Win XP, Win Vista, Win 7, Win 10, OS X 10.3 or better
Turntable platter
Material:	Plastic
Dimensions:	Diameter: Ø 33 cm

Packaging units

PU	EAN	Weight	Dimensions
1	4026397356090	5,00 kg	53cm x 41,5cm x 21cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
10603043-Images-.zip

Publications

On page: 16

Size: 14 MB

OMNITRONIC BD-1380 USB Turntable sil

Name: OMNITRONIC BD-1380 USB Turntable sil
Brand: OMNITRONIC
SKU: 10603043
Price: 199.00 EUR
Availability: InStock

Stock for approx. 12 wk(s)

199,00 €

Find a dealer

Stock for approx. 12 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 10603043

turntable platter 33 cm

Belt drive DJ turntable with USB interface and recording software, silver

Built-in USB port and phono preamplifier, for a high-quality and convenient digitization of analog vinyl records
Sampling rates of 44.1 kHz and 48 kHz in stereo, resolution: 16 bits
Large start/stop button
Strobe lamp for exact speed adjustment
Adjustable anti-skating
Shock-absorbing feet
Switchable phono/line output
Pitch range: ±10%
The device can be connected via USB to the PC
Compatible with Win XP, Win Vista, Win 7, Win 10, OS X 10.3 or better
For application areas such as: Clubs/dancing school; mobile use; mobile djs / entertainer; homerecording and studios
